Chipmakers have been struggling for years to reduce production of compute nodes in an effort to improve the performance, efficiency and load of processors manufactured in their foundries.
Earlier this year, Samsung announced that it had already started manufacturing chips as a 3nm procedure node. Now, the company is laying out its plans for the next five years: Samsung plans to start mass production of 2nm chips until 2025 and 1. 4nm chips until 2027. .
Samsung says it also plans to triple “advanced node” production capacity by 2027, meaning the company would not only produce more powerful processors, but have the ability to produce more than ever before.
Of course, a matrix reduction is just one of the things chipmakers can do with the functionality of next-generation processors. And so, Intel (which has spent years looking to move beyond the 10nm node) has argued that what a company calls a 5nm node or the 7nm chip may not have all the capability you’d find in a competing chip on a higher compute node. Therefore, the company made the decision last year to avoid using nodes to describe its production process (an “Intel 4” chip, for example, will be built on a 7nm node).
That said, AMD’s newest desktop and cellular chips were built using a smaller node than Intel’s newer chips. and while Intel’s chips continue to lead single-core performance, they also have a tendency to consume much more power than AMD’s chips, while providing more than a combined bag in multi-core testing.
So there’s something about all this contraction after all.
